SolaHD電源Silver Line系列技術參數
Input | |
Input Voltage | 100/120/220/230/240 Vac Selectable |
Input Frequency | 47-63 Hz |
Output | |
Line Regulation | for 10% change 0.05% |
Load Regulation | for 50% change 0.05% |
Ripple | 3.0 mV maximum Peak-to-Peak |
DC Output Adjustment Range | ±5% Minimum |
Overvoltage Protection | All 5-Volt outputs include build-in OVP as standard (setting is 6.2 V ±0.4 V) OVP is optionally available on other types |
Transient Response Time | at 50% Load Changes 50 msec. |
Overload Protection | Automatic current limit foldback |
Remote Sensing | Available to compensate for output voltage drop on selected models. 0.5 Vdc |
General | |
Operating Temperature Range | Derate to 40% at +70°C 0 to +50°C |
Storage Temperature Range | -25°C to +85°C |
Temperature Coefficient (Typical) | 0.01% 0°C |
Stability | After warm-up ±.5% |
EMI/RFI | Linear power supplies have inherently low conducted and radiate noise levels |
Cover Option | Derate power by an additional 15% |
Cooling | Forced air. 20 CFM required for full rating |
SolaHD電源Silver Line系列介紹
? 易于安裝的螺釘端子連接
? 封面選項
? 行業標準占地面積
? 通用輸入和認證（115/230 Vac）
? 低噪音、極安靜的直流輸出。 用于噪聲敏感或模擬電路。
? 快速瞬態響應。
? 5 V 型號內置 OVP，12、15 和 24 V 型號可選
? 自動復位過載保護
? 短路保護
? Easy-to-install screw terminal connections
? Cover options
? Industry standard footprint
? Universal input and approvals (115/230 Vac)
? Low noise, extremely quiet DC output. For noise sensitive or analog circuitry.
? Fast transient response. Ideal for test applications.
? Built-in OVP on 5 V models and optional on 12, 15 and 24 V models
? Automatic resetting overload protection
? Short circuit protected
SolaHD電源Silver Line系列其他常用型號：
SolaHD SLS-05-030-1T
SolaHD SLS-05-060-1T
SolaHD SLS-05-090-1T
SolaHD SLS-05-120-1T
SolaHD SLS-12-017T1
SolaHD SLS-12-034T
SolaHD SLS-12-051T
SolaHD SLS-12-068T
SolaHD SLS-15-045T
SolaHD SLS-15-060T
SolaHD SLS-24-012T
SolaHD SLS-24-024T
SolaHD SLS-24-036T
SolaHD SLS-24-048T
SolaHD SLS-24-072T
SolaHD SLS-24-120T
SolaHD Power Supplies NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于SolaHD電源SLS-12-051T的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for SolaHD products, please feel free to dial 0086-21-3100 6702/ send request email to sales@www.agcjj.cn / browse our website:www.www.agcjj.cn.
SolaHD電源Silver Line系列SLS-12-051T技術參數及介紹
