Shaft loading:

100 lbs. radial/50 lbs. axial maximum shaft loading. Bearing life rated at 2X10^9 revolutions minimum at maximum shaft load.

Starting torque:

8.0 oz. in max @25° C

Moment of inertia:

6.25 X 10?-4 oz-in-sec?2

Weight:

4 lbs.

note: except HT-20C @ 7 lbs.

MATING CONNECTOR: (SOLD SEPERATELY)

AMCI Part Number

Military Equivalent

Straight

MS-16

MS3106A16S-1S

90 Degree

MS-18

MS3108A16S-1S

Watertight

MS-161

MS3106F16S-1S

CONNECTOR PINOUT: (MILITARY EQUIVALENT PART #:MS3102E16S-1P)

A

R1

B

R2

C

S4

D

No connection

E

S2

F

S1

G

S3

Note: Connectors are sold separately or as part of a pre-assembled cable.

Note: The HT-20C uses a conduit connection

Note: AMCI recommends using a pipe thread sealant instead of Teflon tape when sealing all conduit connections. The best sealant to use is application dependent and it is the responsibility of the user to choose the correct sealant for the application.

ELECTRICAL SPECIFICATIONS

Input Frequency:

5000 Hz

Rotor Input Voltage:

7.0 V rms

Stator Output Voltage:

6.65 V rms

Transformation Ratio:

0.95 ± 5%

Input Current:

17 mArms max.

note: except HT-20C @ 30 mArms max.

Phase Shift:

10° max.

note: except HT-20C @ 9° max.

Accuracy:

max. error ±7 minutes

ENVIRONMENTAL SPECIFICATIONS

Operating temperature:

-40° C to 125° C (-40° F to 257° F)

Note: HT-20K & HT-20L rated -30° C to 125° C (-22° F to 257°F)

Shock:

50 G's for 11 mSec

Vibration:

15 g's to 2,000 Hz

Enclosure:

refer to mechanical drawings(IP67 rating available on HT-20K, HT-20L, and HT-20C)
