Electric current

Rated current

4 A

Breaking capacity Icn at 230 V AC according to IEC60898-1

6 kA

Rated current at -15°C

5A

Rated current at -10°C

4,9A

Rated current at -5°C

4,8A

Rated current at 0°C

4,7A

Rated current at 5°C

4,6A

Rated current at 10°C

4,5A

Rated current at 15°C

4,4A

Rated current at 20°C

4,2A

Rated current at 25°C

4,1A

Rated current at 30°C

4A

Rated current at 35°C

3,9A

Rated current at 40°C

3,8A

Rated current at 45°C

3,6A

Rated current at 50°C

3,5A

Rated current at 55°C

3,3A

Rated current at 60°C

3,2A

Rated current at 65°C

3A

Rated current at 70°C

2,9A

Architecture

Polart

1P

Trigger characteristics

C

Capacity

Number of modules

1

Main electrical features

Breaking capacity Icn AC according to IEC60898-1

6 kA

Nominal Torque Upper Clamp

2.80 - 2.80 Nm

Nominal torque lower clamp

2.80 - 2.80 Nm

tension

Rated operating voltage Ue

230 - 230V

Supply voltage type

AC

Isolation voltage Ui

500V

Surge voltage resistance

4000 V

frequency

frequency

50 - 60 Hz

Installation, assembly

Nominal torque

2.80 - 2.80 Nm

Type bottom terminal for modular devices

biconnect

Type top terminal for modular devices

Screw connection

360° mounting option

Yes

Security

IP protection

IP20
