SCHNEIDER風閥執行器MD10SR-24M技術參數
Main | |
product or component type | Actuator |
actuator type | Electric |
actuator product series | MD10SR |
product destination | Dampers |
actuator | Rotary |
control type | Automatic reset |
rated supply voltage | 24 V AC/DC |
analogue input range | 2...10 V DC |
feedback signal | 2...10 V DC |
transformer rated power in VA | 5.5 VA |
power consumption in W | 3.5 W |
power consumption in VA | 5.5 VA AC |
hold-in power consumption in W | 2.5 W |
power loss return | Spring return |
control signal | Proportional/modulating |
electrical insulation class | Class III |
tightening torque | 10 lb.in |
position indicator | Stroke indicator on bracket |
lead length | 1 m |
spring return timing | 75 s |
actuator rotation | 95 ° |
rotational range adjustment | 95° maximum (limited by an adjustable end stop) |
IP degree of protection | IP43 |
ambient air temperature for operation | -30…50 °C |
relative humidity | 0…95 % RH, non-condensing |
ambient air temperature for storage | -40…80 °C |
SCHNEIDER風閥執行器MD10SR-24M產品介紹
緊湊型機械彈簧復位阻尼器執行器
用于彈簧復位方向功能的通用安裝
Compact Mechanical Spring Return Damper Actuator
Universal Mounting for Spring Return Directional Function
SCHNEIDER風閥執行器MD10SR系列其他常用型號：
SCHNEIDER MD10SR-T
SCHNEIDER MD10SR-TS
SCHNEIDER MD10SR-24M
SCHNEIDER MD10SR-24TS
SCHNEIDER MD10SR-24T
SCHNEIDER Damper Actuator NEW + ORIGINAL+ ONE YEAR WARRANTY
