BFT噴嘴DN13尺寸圖
BFT噴嘴DN13介紹
Marshall burners are designed to be used on compressed air & gas; they produce two concentrated linear flames parallel to each other to produce two linear flames for a concentrated and controllable heat source.
The DN 13 consists of two parts the Front which contains three stainless steel rolled gauzes, which hide retention holes to help bafle and stabilize the flame, between the gauzes there are two rows of main ports.The front also contains a lock nut to give complete directional control over flame direction.
Secondly the back which contains a round stainless steel gauze either side of a spacer ring to help dissipation of mixture pressure and ensure even distribution of gas mixture.
Marshall燃燒器設計用于壓縮空氣和氣體；它們產生兩個相互平行的集中線性火焰，以產生兩個線性火焰，用于集中和可控的熱源。
DN 13 由兩部分組成，前部包含三個不銹鋼軋制紗網，隱藏固定孔以幫助擋板和穩定火焰，在紗網之間有兩排主端口。前部還包含一個鎖緊螺母，可以完全控制火焰方向。
其次，背面在間隔環的兩側裝有圓形不銹鋼網，以幫助分散混合物壓力并確保氣體混合物的均勻分布。
BFT Marshall burners are designed to operate using compressed air/gas. Gases that can be used are coal gas, natural gas (methane), propane, butane or any mixture of these gases can be used. Gas should be supplied at a low pressure (0.25 psi).
Applications
These are a very popular burner used in many industrial applications where a small concentrated linear flame is required. Among its many uses are annealing, brazing and soldering as well as a variety of roles in the glass and plastics industries, they are widely used on automated flame machinery due to there flexible yet controllable flame pattern。
BFT Marshall 燃燒器設計為使用壓縮空氣/氣體運行。 可以使用的氣體是煤氣、天然氣（甲烷）、丙烷、丁烷或可以使用這些氣體的任何混合物。 應以低壓 (0.25 psi) 供應氣體。
應用
這是一種非常流行的燃燒器，用于需要小型集中線性火焰的許多工業應用。在其眾多用途中包括退火、釬焊和焊接以及在玻璃和塑料行業中的各種作用，由于具有靈活且可控的火焰模式，它們被廣泛用于自動化火焰機械。
BFT噴嘴其他常用型號：
BFT DN13
BFT DN 9
BFT SN 14
BFT FTN 9
BFT Fueling Nozzle NEW + ORIGINAL+ ONE YEAR WARRANTY
