HONEYWELL燃燒控制器EC7890B1010/U規格描述
Product Specifications | |
Application | On-Off Primary Control |
Dimensions (in.) | 5 in. wide x 5 in. high x 5 1/4 in. deep with Q7800A Subbase x 6 3/32 in. deep with Q7800B Subbase |
Dimensions (mm) | 127 mm wide x 127 mm high x 133 mm deep with Q7800A Subbase x 155 mm deep with Q7800B Subbase |
Weight (lb) | 1 lb 13 oz |
Weight (kg) | 0.8 kg |
Comments | Includes Shutter Drive Capability |
Frequency | 60 Hz (±10%),50 Hz |
Voltage | 220 to 240 Vac (+10, -15%) |
Shipping and Storage Temperature Range (F) | -40 F to +140 F |
Shipping and Storage Temperature Range (C) | -40 C to +60 C |
Flame Establishing Period - Pilot | 4 sec or 10 sec |
Flame Establishing Period - Main | Intermittent |
Required Components | Q7800A,B Universal Wiring Subbases. R7847, R7848, R7849, R7851, R7852, R7861, or R7886 Flame Signal Amplifier. |
Pilot Type | intermittent |
Vibration | 0.5 G environment |
Approvals, Factory Mutual | Report No. 1D0A1.AF |
HONEYWELL燃燒控制器EC7980系列產品介紹
Microprocessor-based integrated primary burner control for automatically fired gas, oil or combination fuel single burner applications. Provides level of safety, functional capability and features beyond conventional controls.
Features
Functions include automatic burner sequencing, flame supervision, system status indication, system or self diagnostics and troubleshooting.
Subbase and amplifier are required for operation.
Options include PC interface, keyboard display module, DATA CONTROLBUS? MODULE, remote display module, first-out expanded annunciator, and COMBUSTION SYSTEM MANAGER? software.
Five LEDs provide sequence information.
Interchangeable plug-in flame amplifiers.
Optional local or remote annunciation of operation and fault information.
Nonvolatile memory retains history files and sequencing status after power loss.
Optional remote reset capability.
Optional report generation.
Selectable relight or lockout on loss of flame.
基于微處理器的集成式主燃燒器控制，適用于自動燃燒氣體，燃油或混合燃料的單燃燒器應用。 提供超越常規控制的安全級別，功能能力和功能。
特征
功能包括自動燃燒器排序，火焰監測，系統狀態指示，系統或自我診斷和故障排除。
操作需要基座和放大器。
選件包括PC接口，鍵盤顯示模塊，DATA CONTROLBUS?模塊，遠程顯示模塊，先進的擴展信號器和COMBUSTION SYSTEM MANAGER?軟件。
五個LED提供序列信息。
可互換的插入式火焰放大器。
可選的本地或遠程操作和故障信息通知。
掉電后，非易失性存儲器保留歷史文件和排序狀態。
可選的遠程重置功能。
可選的報告生成。
失火時可選擇重燃或鎖定。
HONEYWELL燃燒控制器EC7980系列其他常用型號：
HONEYWELL EC7890B1010/U
HONEYWELL EC7890B1010
HONEYWELL EC7890A1037
HONEYWELL RM7890A1064
HONEYWELL RM7890B1055
HONEYWELL EC7850A1072
