Dimension（W×H×D）

34×115×101.6 mm

Power dissipation

19.5W

Power supply features

Rated input voltage

24V DC

Input voltage range

20.4~28.8V DC

Input current

0.8A

Reverse polarity protection

Yes

Bus power supply voltage

+5V DC

Bus supply current

1.6A

LED indicator characteristics

24V power indicator (green)

On: 24VDC power supply is normal,
off: no 24VDC power supply

SF indicator (red)

On: system failure, off: no error

BF indicator (red)

On: bus failure, off: no error

FRCE indicator (yellow)

On: items are forced,
Off: no items are forced.
< note > can also be controlled via the scrapers command.

RMC indicator (green)

On: CPU has successfully communicated with the remote server (dial switch 3 is ON and Ethernet port parameters have been configured correctly)

Off: CPU fails to communicate with the remote server or disallows communication with the remote server (allows and disallows communication with the server via dialing switch)

Run indicator (green)

On:system runs,
off: the system stops

STOP indicator(orange)

On: system stops;
Off: system runs

Expand I/O capabilities

Maximum number of racks of 1CPU

4

Maximum number of modules supported per rack

Support up to 8 modules except  power, CPU, relay module
