Skewed armature design provides ultra smooth operation (i.e. low cogging torque) at all speeds.

Various electrical windings are available as standard to suit both low and high voltage amplifiers in order to provide optimum speed and torque characteristics. Optional custom electrical windings are available to meet virtually any requirement.

Worldwide standard mounting configurations are available (Square, Round, NEMA 42, and NEMA 56C).
Optional custom mounting configurations are available to meet virtually any requirement.

Industry standard lead termination configurations. (i.e. MS connectors, fluid tight strain relief cable exit, NPT hole with flying leads and terminal boxes)

Optional industry standard feedback devices. (i.e. high performance silver commutator tachometers, and encoders)

Class H insulation standard.

Standard operating temperature is dependent on the feedback device installed. Motors with resolver feedback can be specially configured to operate down to -40°C.

Optional 24VDC holding brakes are available.

Optional IP65 sealing is available

RoHS compliant.

CE marked

UL Recognized Component for US and Canada.

GM4000 SERIES ENVIRONMENTAL CONDITIONS

Storage Temperature:

-20°C to 70°C

Operating Temperature:

Standard: -20°C to 40°C, without derating, derate torque 10% per 10°C above 40°C
Special: -40°C to 40°C, without derating, derate torque 10% per 10°C above 40°C

Humidity:

5% to 95% relative humidity, non-condensing

Altitude:

Up to 1000m without derating, derate torque 10% per 1000m above 1000m
