BEKA氣動泵單元2566系列產品參數
Specification | |
Output rate | 3 cm /stroke 3 9,5 cm /stroke 3 15 cm /stroke |
Ratio | with 3 cm /stroke 1 : 32 3 with 9,5 cm /stroke 1 : 12 3 with 15 cm /stroke 1 : 8 |
Flow pressure | 3 - 8 bar |
Lubricant | oil, 20 - 700 mm /s2 fluid grease (according to release list) |
Temperature range | medium 0 - 70°C ambient 0 - 40°C |
BEKA氣動泵單元2566系列產品介紹
技術說明
256型氣動泵通過動態計量閥提供6個潤滑點。
操作方法
活塞加壓后開始潤滑。
壓縮空氣的調節方式必須使溢流閥僅在計量閥潤滑后才打開。這樣可以確保所有計量閥都向潤滑點供應足夠的潤滑劑。
當3/2向電磁閥切換時，活塞被推入其原始位置。通過溢流閥將主管道的壓力降至<1 bar，計量閥將潤滑劑重新堆積，以備下次潤滑時使用。同時，潤滑劑從油箱中吸出，用于下一個沖程。
計量閥的總劑量不應超過泵的輸送量的60％。
Technical description
The pneumatic pump unit of type no. 256 supplies 6 the lubrication points via dynamic metering valves.
Method of operation
Lubrication starts when the piston is pressurized.
The compressed air has to be adjusted in a way that the pressure relief valve only opens when alI metering valves have lubricated. This ensures that all metering valves supply enough lubricant to the lub points.
When the 3/2-way solenoid valve switches, the piston is pushed into its original position. The main line is relieved down to < 1 bar by the relief valve and the metering valves restack the lubricant for the next lubrication pulse. At the same time, the lubricant is sucked out of the reservoir for the next stroke.
The metering valves’ total dosage should not exceed 60% of the pump’s delivery quantity.
選型參考
BEKA氣動泵單元2566系列其他常見型號：
BEKA 2566.03.00.000
BEKA 2566.09.00.000
BEKA 2566.15.00.000
BEKA Pneumatic pump units NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于BEKA氣動泵單元2566.15.00.000 P605的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for BEKA products, please feel free to dial 0086-21-3100 6702/ send request email to sales@www.agcjj.cn / browse our website:www.www.agcjj.cn.
BEKA氣動泵單元2566.15.00.000 P605產品參數
