REXROTH柱塞馬達A10FM58/52W-VWC10N000規格描述
Axial piston unit | A10F:Swashplate design, constant, nominal pressure 280 bar (4100 psi), maximum pressure 350 bar (5100 psi) |
Operating mode | M: Motor, open and closed circuit |
Size (NG) | 058:For geometric displacement, see table of values, page 7 |
Series | 52:Series 5, index 2 |
Direction of rotation | W:Alternating |
Sealing material | V:FKM (fluorocarbon rubber) |
Drive shaft | W:For reduced torque |
Mounting flange | C: Based on ISO 3019-1 (SAE); 2 hole |
Working port | 10N00:A and B; laterally; same side Fastening thread metric |
Valves | 0: Without valve |
REXROTH柱塞馬達A10FM58/52W-VWC10N000規格
規格
適用于標準應用的中壓馬達
尺寸 18 ' 63
額定壓力 280 巴
最大壓力 350 巴
開式和閉式回路
Specifications
Medium pressure motor for standard applications
Size 18 ' 63
Nominal pressure 280 bar
Maximum pressure 350 bar
Open and closed circuits
REXROTH泵AZPB系列其他常用型號：
REXROTH A10FM58/52W-VWC10N000
REXROTH A10FME45/52 95N000-SO687
REXROTH A A10F M 23 /52W-VRC60N000
REXROTH A A10F M 63 /52W-VWC60N000
REXROTH A A10F M 45 /52W-VCC10N000
REXROTH AL A10F E 10 /52R-VCH16N002
REXROTH A A10F E 18 /52W-VCH16N000
REXROTH A A10F M 18 /52R-VRC16N002
REXROTH A A10F M 37 /52R-VRC10N002
REXROTH A A10F M 45 /52L-VWC10N002
REXROTH A A10F M 45 /52W-VPC10N007
