General

Weight

0.16 kg (0.35 lbs)

Installation orientation

Optional

Ambient temperature range

-30 to 60 °C (-22 to 140 °F)

Hydraulic

Max. operating pressure

350 bar (5000 psi)

Max. proof pressure

420 bar (6000 psi)

Flow range

0.5 - 40 l/min (0.1 - 11 gpm)

Fatigue cycle life

1 million cycles at 350 bar

Max. internal leakage

20 drops/min.

Fluid temperature range

-20 to 80 °C (-4 to 176 °F)

Fluids: Mineral-based or synthetics with lubricating properties at
viscosities of 20 to 380 mm2/s (cSt)

Installation torque

39 - 51 Nm (29 - 38 ft-lbs)

Recommended degree of fluid
contamination

Nominal value max. 10 μm
(NAS 8) ISO 4406 19/17/14

MTTFd

150 years see RE 18350-51

Cavity

CA-08A-2N see 18325-70

Lines bodies and standard assemblies

Please refer to section “Hydaulic integrated circuit” or consult factory

Seal kit – version 1

code RG08A2010520100
material no.  R90110143

Seal kit – version 2-3

code RG08A2010530100
material no.  R901101544

Seal kit coil

code  RG12A1PNBR7010
material no.  R934003958

Other technical data

See data sheet 18350-50

Electrical

Type of voltage

DC voltage

Coil type

S8-356 see 18325-90

Supply voltage

See data sheet 18325-90

Nominal voltage

± 10%

Power consumption

20 W

Duty cycle coil

See characteristic curves %

Type of protection

See data sheet 18325-90

Note: Coils must be ordered separately
