General

Weight

0.75 kg (1.7 lbs)

Installation   orientation

Optional

Ambient temperature   range

-25 to 60 °C (-13 to   140 °F)

Hydraulic

Max. operating pressure

350 bar (5000 psi)

Flow range

2.5-70 l/min (0.66 -   18 gpm)

Max. internal leakage

15 drops/min.

Fluid temperature   range

-20 to 80 °C (-4 to   176 °F)

Fluids:

Mineral-based or   synthetics with lubricating properties at viscosities of 15 to 380 mm2/s   (cSt)

Installation torque

50 - 55 Nm (37 - 41   ft-lbs)

Recommended degree of   fluid contamination

Nominal value max. 10   μm (NAS 8) ISO 4406 19/17/14

MTTFD

150 years see RE   18350-51

DC

90% * according to ISO   13849-1/2

Lines bodies and standard   assemblies

Please refer to   section “Hydaulic integrated circuit” or consult factory

Seal kit – version 31

code RG17E201053010
  material no. R934003563

Electrical

Type of voltage

DC voltage

Nominal voltage

± 10%

Power consumption

20 W

Duty cycle coil

100%
