HONEYWELL探測器MiniMAX XP-O2規格描述
Construction | |
General | Serviceable, portable single gas monitor for personal protection against Oxygen and toxic gas hazards |
Calibration | Time between calibrations is maximised utilizing cell decay compensation facility. The maximum time between calibrations is 12 months# |
Operating Life | Sensor (replaceable) Minimum of 2 years Battery (replaceable) 3 years* |
Operating Temperature | -20°C to +50°C (-4°F to +122°F) (temperature compensated) |
Humidity | 5-95% RH (non-condensing) |
Audible Alarm | 95db at 10cm (4in) |
Visual Alarm | High intensity Red LEDs |
Vibrating Alarm | Standard |
Display | Ultra clear backlit LCD displays gas levels & instrument status |
Sensor Type | Electrochemical (replaceable) |
Battery Type | Lithium CR2, 3.0V (replaceable) |
Diagnostics | Self-test of circuitry, battery, LCD, and software. Sensor test using patented Reflex? sensor technology |
Environmental | |
IP Rating | IP54 (Minimum) |
Intrinsic Safety | North America: Class 1, Div 1, Groups A, B, C, D, T4 (UL/cUL) Europe: EEx ia IIB T4 (CENELEC) II 2G EEx ia IIC T4 (ATEX) |
RFI/EMC | CE EN50270:1999 and EN55011 |
Dimensions | 93mm (H) x 50mm (W) x 27mm (D) (3.6” x 2” x 1.1”) excluding clip |
Weight | Toxic 81.5g (2.8oz) Oxygen 93.0g (3.3oz) |
HONEYWELL探測器MiniMAX XP-O2性能特點
The XP Series is an easy to use, personal gas detector, designed for monitoring the atmosphere for potentially hazardous levels of oxygen deficiency or toxic gas. It has built-in cell decay compensation, thermal shock protection, and Reflex?, a patented sensor failure detection system, for maximum reliability.
SAFETY INFORMATION
Substitution of components may impair intrinsic safety
Only use specified batteries: Energizer? CR2 or Sanyo CR2
Do not activate the detector after the date on the packaging
Perform a self-test prior to each day’s use (See Section 6)
Do not use in oxygen-enriched atmospheres
Periodically test the sensor’s response to gas by exposing the detector to a target gas concentration that exceeds the alarm set points. Manually verify that the audible, visual and vibrating alarms are activated.
Exposure to extremely high levels of over-range gas may cause temporary loss of sensor accuracy. Allow detector to stabilize in a zero gas atmosphere before reuse. It is recommended to perform a sensor response gas test prior to reuse.‘’
XP系列是易于使用的個人氣體探測器，設計用于監視大氣中是否存在潛在的有害的氧氣不足或有毒氣體。它具有內置的電池衰減補償，熱沖擊保護以及獲得專利的傳感器故障檢測系統Reflex?，以實現最大的可靠性。
安全信息
更換組件可能會損害本質安全
僅使用指定的電池：Energizer?CR2或Sanyo CR2
包裝上的日期之后請勿激活檢測器
每天使用前進行自檢（請參閱第6節）
不要在富氧氣氛中使用
通過將檢測器暴露于超出警報設定點的目標氣體濃度，定期測試傳感器對氣體的響應。手動驗證聲音，視覺和振動警報已激活。
暴露于極高水平的超量程氣體中可能會導致傳感器精度的暫時損失。在重新使用之前，讓檢測器穩定在零氣氛中。建議在重新使用之前進行傳感器響應氣體測試。
HONEYWELL探測器XP系列其他型號：
HONEYWELL XP-LBL-O2
HONEYWELL XP-LBL-CO
HONEYWELL XP-LBL-H2S
HONEYWELL XP-LBL-CL2
HONEYWELL XP-LBL-SO2
HONEYWELL XP-LBL-NO2
HONEYWELL XP-LBL-HCN
HONEYWELL XP-LBL-NH3
HONEYWELL XP-LBL-H2
HONEYWELL MiniMAX-XP-07
HONEYWELL MiniMAX-XP-BATT
HONEYWELL HOR132
HONEYWELL HOR133
