CIRCLE VALVE閥HP532B-2M技術參數
Series | HP500 |
Body Material | Brass |
O-Ring Material | Viton |
Valve Size | 1/4 in |
End Connections (Inlet/Outlet) | Popoff male pipe |
Operating Pressure | 150 to 575 psig |
Cracking Pressure | 150 to 575 psig |
Cracking Pressure Tolerance | ±5% |
Operating Temperature | -20 to 400 oF |
Spring Material | 17-7 PH Stainless Steel |
Dim. A | 1.17 in |
Hex | 5/8 in |
Weight | .06 lbs |
Optional Body Material | 316 Stainless Steel |
Optional End Connections | 1/4" Male BSPT x 1/4" Female BSPT |
CIRCLE VALVE閥HP532B-2M介紹
非常準確的開啟壓力
高達 95% 開啟壓力的零泄漏
100% 閥座泄漏測試
防干擾的調整
大多數型號均可獲得 PED 認證和 CE 標志
Very accurate cracking pressure
Zero leakage up to 95% of cracking pressure
100% seat leakage tested
Tamper-proof adjustment
PED certifications and CE marking available for most models
CIRCLE VALVE閥HP500系列其他常用型號：
CIRCLE VALVE HP532B-2M-280
CIRCLE VALVE HP532B-2M
CIRCLE VALVE HP532B-2MP
CIRCLE VALVE HP532B-4M
CIRCLE VALVE HP532B-4MP
CIRCLE VALVE HP559B-2M
CIRCLE VALVE HP559B-2MP
CIRCLE VALVE HP559B-4M
CIRCLE VALVE HP559B-4MP
CIRCLE VALVE HP533B-2M
CIRCLE VALVE HP533B-2MP
CIRCLE VALVE HP533B-4M
CIRCLE VALVE HP533B-4MP
CIRCLE VALVE HP562B-2M
CIRCLE VALVE HP562B-2MP
CIRCLE VALVE HP562B-4M
CIRCLE VALVE HP562B-4MP
CIRCLE VALVE HP532T1-2M
CIRCLE VALVE HP532T1-2MP
CIRCLE VALVE NEW + ORIGINAL+ ONE YEAR WARRANTY
