ANYBUS網關AB7646-F規格描述
Technical specifications | |
Dimensions(L?W?H) | 114 x 44 x 127mm or 4,49 x 1,73 x 5,00" |
Weight | 400g or 0,880 lbs |
Operating temperature | -25 to +65 °Cor-13 to +149 °F |
Storage temperature | -40 to +85 °Cor-40 to +185 °F |
Power supply | 24 VDC +/- 20% via 2-pole 5.08 mm Phoenix pluggable screw connector |
Current consumption | max. 400mA (Typical 200mA) |
Enclosure material | Aluminium and plastic |
Installation position | Vertical / Flat* |
Galvanic isolation | YES, on both BUS/Ethernet side |
Mechanical rating | IP20, NEMA rating 1 |
Mounting | DIN-rail (EN 50022 standard) |
I/O configuration | via USB port withAnybus Configuration Manager software |
Certifications | CE,CULUS,RoHS |
ANYBUS網關AB7646-F產品信息
Anybus X-gateway – PROFIBUS Master – PROFINET-IO Device
The Anybus X-gateway allows you to seamlessly inter-connect PLC control systems and their connected devices between PROFIBUS and PROFINET networks.
FAST COPYING OF I/O DATA
The X-gateways primary function is with the fast transfer of cyclic I/O data between the two networks. This offloads your PLC from working with additional calculations. The gateway acts as a Master on the PROFIBUS network and a Device on the PROFINET network. The data transmission is completely transparent with a maximum data capacity of 512 bytes in each direction.
EASY CONFIGURATION - NO PROGRAMMING REQUIRED!
The connection between the two networks is quickly set up in the Anybus Configuration Manager software, included with the X-gateway. No programming skills are needed to set up the X-gateway. As factory default the X-gateways have a pre-defined I/O size of 20 bytes I/O.
Anybus X-gateway – PROFIBUS 主站 – PROFINET-IO 設備
Anybus X-gateway 允許您在 PROFIBUS 和 PROFINET 網絡之間無縫互連PLC控制系統及其連接的設備。
快速復制I/O數據
網關的主要功能是在兩個網絡之間快速傳輸循環I/O數據。 這會減輕您的PLC處理額外計算的負擔。 網關在PROFIBUS網絡上充當主站，在 PROFINET 網絡上充當設備。數據傳輸是完全透明的，每個方向的最大數據容量為512字節。
輕松配置 - 無需編程！
兩個網絡之間的連接可在 X-gateway 附帶的Anybus配置管理器軟件中快速建立。 設置X-gateway不需要任何編程技能。 作為出廠默認設置，X網關具有20字節I/O的預定義I/O大小。
