RIM Tach? 6200特點

堅固型大功率編碼器，擁有不銹鋼和延性鑄鐵結構

新傳感器技術，更寬間隙，可靠性更好

額外重型軸承，使用壽命更長

方便的 LED 燈盡顯編碼器功能

底角安裝或 56C 型面安裝，適合 " 花盆 " 或皮帶傳送應用

Features

?  The stand alone, foot mounted or accessory bracketdesign is ideal for close coupled, belt, or wheel driven setups

?  Modular design incorporates extra severe duty bearings fora longer encoder life

?  Stainless steel and cast iron construction

?  Magnetoresistive sensor technology is unaffected by grease,salt water, dust, or other common mill contaminants

?  Interchangeable magnetoresistive sensor modules for fastand easy field service

?  Resolutions up to 2048 PPR with optional index pulse

?  Optional RIM Tach? Shaft Grounding Brush

RIM Tach? 6200 has been specifically designed to directly address the needs of the process industry.The heavy duty digital tachometer is constructed to be used as either a stand alone, foot mounted solution, or assembled to anaccessory bracket as a 56 C face for common mill applications such as close coupled, belt, or wheel driven setups. The 6200provides an easy solution for reduction of downtime of maintenance, and fast installation. Providing the most reliable, mechanical,electrical, and environmental features available in digital tachometers today.

Rugged, Mill Duty Construction

The durable RIM Tach?  6200 was designed for hostileenvironments. The mill duty, cast iron construction ofthe 6200 accepts stainless steel sensor modules withpatented magnetoresistive technology. The outputs areavailable as either single or dual outputs and are completely isolated from one another. The modular designfeatures extra severe duty bearings (1.875” OD) toensure longer life under heavy loads

Reliable Magnetoresistive Technology

The patented technology of the Rim Tach? 6200 is incorporated into a heavy duty, one piece sensor module, withencapsulated surface mount electronics. The advancedmagnetoresistive sensor modules are immune to commonmill contaminants (water, oil, grease, dirt, shock, and

vibrations) and overall harsh environments. This state-of-the-art technology allows for much higher resolutionsproviding resolutions up to 2048 pulses per revolution.With the addition of a RIM Tach? Shaft Grounding Brush,induced shaft currents “drain” away, preventing prematurematerial weakening of large AC and DC motor bearings,and their consequent failure.

Easy Installation

The mill duty latching connectors are standard. Thesesealed connectors are simple to wire by inserting thestripped conductor in the plug and tightening the screwterminals. There is noneed to field solder or to strugglewith a crimp pin. The unit easily mounts on a standardNEMA 56 C face (4.5”) and requires no gap adjustments. The pulse count output is very easy to change,just remove four screws and slide the desired pulse countsensor module in place.

愛澤工業(IZE INDUSTRIES)特價經銷、常用備件型號：

DANAHER編碼器RIM1250系列

DANAHER編碼器RIM6200系列

DANAHER編碼器RIM8500系列

DANAHER編碼器HSD35系列

愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的首選渠道。

如果有任何關于美國DANAHER編碼器RIM6200系列的疑問，請隨時與我們聯系，（021-3100 6702），我們將盡全力解決您的問題。

有關美國DANAHER編碼器RIM6200系列更詳細的信息或者購買美國DANAHER相關產品，請聯系愛澤工業。
